Corvette ECS 2200X 10-Rib Supercharger Conversion Kit : C7 Z06
When the new 2015 C7 Z06 was released and we started modifying them we quickly came to find out the factory Eaton 1.7L supercharger was not going to keep up for long and saw them max out at about the 750whp range.
Soon after we started development on a conversion kit that would remove the factory supercharger and replace it with a custom sheet-metal intake manifold and add our proven billet impeller NOVI 2200X 10-Rib Belt Drive C7 supercharger system for customers with power goals between 1,100 to 1,300whp.
-ECS C7 10-Rib NOVI 2200-X kit.
-Innovators West balancer and 10-Rib direct drive hub.
-Gates RPM Racing 10-Rib supercharger belt.
-Paxton NOVI 2200-X billet impeller supercharger:
Internal Step-Up Ratio: 3.45:1
Max Speed: 65,000 RPM
Max Boost: 30+ PSI
Max Flow: 1,950 CFM
Max Power: 1,400+ HP
Peak Efficiency: 78%
-Dual TiAL Q 50mm blow off valves.
-G1 Pro LT4 black sheet metal intake manifold.
-Optional LME Billet LT4 Intake Manifold +$2,995*
-ECS C7 Braided AN oil feed and drain line kits.
-Retains all factory transmission and oil coolers.
-Black or Polished finishes available for brackets and supercharger at no extra cost.
-100% Reversible installation back to stock if desired.
