Corvette ECS 2200HD 8-Rib SC Conversion Supercharger Kit : C7 Z06


C7 Z06 Corvette ECS 2200HD 8-Rib SC Conversion Supercharger Kit

When the new 2015 C7 Z06 was released and we started modifying them we quickly came to find out the factory Eaton 1.7L supercharger was not going to keep up for long and saw them max out at about the 750whp range.
Soon after we started development on a conversion kit that would remove the factory supercharger and replace it with a custom sheet-metal intake manifold and add our proven NOVI 2200HD C7 supercharger system for customers with power goals between 750-900 whp.
System includes:
• ECS C7 8-Rib NOVI 2200HD Kit Black Finish
• Innovators West balancer and 8-Rib direct drive dub.
• Gates RPM Racing 8-Rib supercharger belt.
• Paxton NOVI 2200 HD oil fed supercharger:
• Internal Step-Up Ratio: 3.45:1
• Max Speed: 60,000 RPM
• Max Boost: 27 PSI
• Max Flow: 1,450 CFM
• Max Power: 1,000 HP
• Peak Efficiency: 76%
• G1 Pro LT4 black sheet metal intake manifold. or
• Late Model Engines LT4 billet intake manifold black anodized.
• ECS C7 Braided AN oil feed and drain line kits.
• Retains all factory transmission and oil coolers.
• 100% Reversible installation back to stock if desired.
